RF cables for modems with TNC antenna connector
CRF-1 (YC1101)
- RG58, length 1 meter with TNC male / TNC female -connectors
CRF-5F (YC1105) / CRF-5M (YC1106)
- RG-58, length 5 meter with TNC male / TNC female -connectors OR CRF-5M TNC male / TNC male -connectors
CRF-50 (YC1150)
- Length 50 cm with TNC male / TNC male from band-pass filter to radio
ECOFLEX10 (YC1004)
- Low loss (0.9 dB / 10 m) cable for cable lengths over 20 meter with N or TNC -connectors.
ECOFLEX15 (YC1005)
- Low loss (0.6 dB / 10 m) cable for cable lengths over 20 meter with N -connectors.
Interface cables for modems with D15 data connector (SATELLINE-EASy, -3AS VHF)
CRS-2M (YC0103) / CRS-2F (YC0104)
- Length 2 meter, includes power supply wires, with D15 / D9 male OR CRS-2F female -connectors
CRS-9M (YC0203)
- Length 2 meters, with D9 male / D9 male connectors
CRS-PB (YC0501)
- Length 2 meter, includes power supply wires, with D15 / D9 male -connectors for RS-485 interface
CRS-SAE-8-pin (YC0372)
- Length 2 meter, includes SAE power connector, with D15 / ODU 8-pin male- connectors
CRS-RJ45 (YC0280)
- Length 2 meter, with D15 / RJ45 male -connectors
CRS-TSU (YC0271)
- Length 2 meters or 50 cm, with D15 male / D15 female connectors, to be used between SATELLINE radio modems and I-LINK 100
CRS-NMS (YC0302)
- Length 1.5 meters, with D15 male / 2 x D9 female connectors from Master modem to user system and NMS PC, including power supply wires
Cables for EASy Pro 35W and Compact-Proof models
CRS-35W 8-pin (YC0368)
- 2 m cable ODU 8-pin male / D9 female
CRS-35W 8-/7-pin (YC0369)
- 2 m cable ODU 8-pin male / 7-pin male
CRS-35W 8-/8-pin (YC0359)
- 2 m cable ODU 8-pin male / 8-pin male
CRS-35W 8-/8-pin (0/30) (YC0374)
- 2 m cable 8-pin male (0 deg) / 8-pin male (30 deg)
Interface and Power Cables for SATEL Compact-4BT
DC / RS232 (YC0400)
- Cable 1 m, M12 / D9 female / 2.1 mm DC jack male
DC / USB (YC0401)
- Cable 1 m, M12 / USB A plug / 2.1 mm DC jack male
Please contact your local distributor to get more information regarding cable types.
